testo 315-3 - Appareil de mesure de CO/CO2 pour mesures ambiantes

Testo · testo 315-3

testo 315-3 - CO and CO2 meter for ambient measurements

Name: testo 315-3 - CO and CO2 meter for ambient measurements
Brand: Testo
SKU: testo 315-3

The high-quality testo 315-3 is an easy-to-use, ruggedly designed CO and CO2 meter that enables you to carry out quick and reliable ambient measurements according to DIN EN 50543 standard.

Request a quote Datasheet

Category: Measuring instruments · CO meters

Specifications by model

General technical data	Value
Operating humidity	0 to 95 %RH
Weight	200 g
Dimensions	190 x 65 x 40 mm
Operating temperature	0 to +40 °C
Ingress protection rating	IP 40 according to EN 60529
Standards	According to EN 50543
EU/EC directives	2004/108/EG
Interfaces	IRDA / Bluetooth optional
Rechargeable battery type	Lithium polymer battery pack
Battery life	10 h of measurement (at +20 °C); mains operation possible
Battery charging	In the instrument, via the power supply unit
Charging options	In the instrument, via the power supply unit
Storage temperature	-20 to +60 °C

Plug-in humidity module - capacitive	Value
Measuring span	+5 to +95 %RH
Accuracy	±2.5 %RH (5 to +95 %RH)
Resolution	0.1 %RH

Ambient CO₂	Value
Measuring span	0 to 10000 ppm
Accuracy	500 ppm (6000 to 10000 ppm) · ±300 ppm (0 to 4000 ppm) · 8 % of mv (4000 to 6000 ppm)
Resolution	10 ppm

Ambient CO	Value
Measuring span	0 to 100 ppm
Accuracy	±5 ppm (>20 ppm) · ±3 ppm (0 to 20 ppm)
Resolution	0.5 ppm

Temperature	Value
Measuring span	-10 to +60 °C
Accuracy	±0.5 °C (±1 Digit)
Resolution	0.1 °C

Full description

Cutting-edge technology, easy-to-use, rugged design. These are just a few of the features which make the testo 315-3 stand out head and shoulders above the rest. The CO andCO2 meter is designed to measure carbon monoxide and carbon dioxide parallel in heating systems and ventilation ducts. The readings are presented on an easy-to-read display. A visual and audible alarm are activated when CO/CO2 thresholds are breached. The thresholds can be adjusted to suit your range of applications. The intelligently designed meter has an energy-saving lithium polymer rechargeable battery and powers off automatically when not in use. And here’s yet another practical feature: the CO and CO2 meter for ambient measurements can also be used in combination with the testo 330-2 flue gas analyzer. The CO/CO2 readings can be transferred directly to the analyzer via the meter’s infrared interface. Tune up your CO and CO2 meter with a range of accessories for even more possibilities Your testo 315-3 is already well equipped to meet all the demands you would put on a CO and CO2 meter. The following accessories are designed to allow you to customize your meter to suit your own individual requirements: • TopSafe protective casing: water and dirt repellent; provides your testo 315-3 CO and CO2 meter with protection in wet and dirty conditions • Testo turbo printer: The testo turbo printer enables you to print out on site and provide your customers with the necessary documentation. The results are transferred to the printer via the CO and CO2 meter’s infrared interface • Temperature/humidity module: allows you to carry out quick and reliable temperature and humidity measurements Key benefits: • High-precision electrochemical CO sensor, shock resistant infrared CO2 sensor • Visual and audible alarm when thresholds are breached – adjustable thresholds • Rugged design • TÜV certified according to DIN EN 50543 standard Scope of delivery: CO and CO2 meter for ambient air measurements, USB power adaptor, cable.
