TEMPSENS · P250C
P250 C Portable Pyrometer
Temperature range: 450°C to 1400°C
Price on request
Details
TEMPSENS · P250
P250 Portable Pyrometer
Temperature range: 210°C….1350°C 250°C….1800°C 300°C….2500°C
Category: Industrial sensors · Portable pyrometers
Specifications by model
| Characteristic | Value |
|---|---|
| Plage de température | 210°C….1350°C 250°C….1800°C 300°C….2500°C |
| Domaine spectral | 1.6 µm |
| Type de photodétecteur | InGaAs |
| Émissivité | 0.1….1.0 adjustable |
| Temps de réponse | 5 msec in Numerical Mode 10 msec in Graphical Mode 10 msec (When data storage is ‘ON’) |
| Tolérance | ± 0.3% of the measured value + 1°C |
| Répétabilité | 0.1% of reading in °C + 1°C |
| Options de visée | Optimized through lens view finder with dioptry correction -2.5 dpt. to +2.5 dpt |
| Data Storage | 4000 Values, Storage of Measurement Value, Date, Time, Emissivity |
| Storage Interval | OFF, 10 msec, 20 msec, 100 msec, 1 sec, 10 sec, 100 sec, 500 sec |
| Afficheur | Left side: LCD Display, 128 x 64 pixels illuminated 3 value per sec.; last value is displayed for another 10 sec after finishing measurement (Hold Function) Additional Built in LED display in the view finder |
| Résolution | LED inside : 0.1°C upto 1000°C after this 1°C LCD outside : 0.1°C upto 1000°C after this 1°C |
| Parameters Setting Via Side Keypad | Emissivity, Peak Picker(Clear Time)(tCL), Average, Storage Interval, Temperature Unit (°C/°F), Auto Off Time, Date, Time |
Full description
P250 is specially designed portable IR pyrometer for non contact temperature measurement between 210°C to 2500°C in demanding industrial environments. The Instruments feature high accuracy. The multi functional bright back light additional LCD graphic display panel provides an indication of status and configuration of pyrometer together with measurement mode. The measuring result is shown and can be analyzed directly on site. The bright through the lens sighting gives a precise definition of the target spot.The portable pyrometer provides fast, simple data logging with USB connecvity to download this data to PC for analysis. . The fast response time within milliseconds allow exact measurement of fast moving object. The large data storage (data store up to 4000 values) of measurement offers the best possibility for analyzing the data.
• Temperature display in the view finder and on the multi function display
• Measuring Functions: Normal, Average , Maximum
• Standard USB Connecvity: USB Options for Communicang to PC
• Small Spot Sizes
• Large data storage for data analysis(Data storage up to 4000 values)
• Additionally the instruments are completed via large display and easy designed keypad for selecting and changing of all available functions and settings
• Numeric and Graphic LCD display on portable pyrometer
• User friendly PC software for communication
