CITEC · 806-82
Series BDT 13 — all stainless differential gauges, ΔP 0…100 mbar to 0…16 bar
All stainless steel
Category: Industrial sensors · Differential pressure gauges
Full description
• All stainless steel
• Ø 100, 150 mm
• ΔP: 0...100 mbar to 0...16 bar
• Maximum static pressure: 100 bar
• Accuracy ±2.5
• ATEX version (optional)
The BDT 13 series gauges are intended mainly for measuring differential pressures in chemical and petrochemical applications.
The measuring system consists of 2 stainless steel diaphragms linked by a mechanical assembly that transmits the pressure to the gauge pointer.
This gives very good resistance to static pressure.
